1.配置MHA脚本
|
1 2 3 |
[root@db03 ~]# vim /service/mha/app1.cnf [server default] master_ip_failover_script=/service/mha/master_ip_failover |
3.编写脚本
1）上传脚本
|
1 2 3 4 5 6 7 8 9 10 |
#解压manager节点的tar包有脚本 [root@db01 ~/mha4mysql-manager-0.56/samples/scripts]# ll 总用量 32 -rwxr-xr-x 1 4984 users 3648 4月 1 2014 master_ip_failover #上传现成的脚本 [root@db03 ~]# cd /service/mha/ [root@db03 /service/mha]# rz master_ip_failover #授权执行权限 [root@db03 /service/mha]# chmod +x master_ip_failover |
2）配置脚本
|
1 2 3 4 5 6 7 |
[root@db03 /service/mha]# vim master_ip_failover ... ... my $vip = '172.16.1.55/24'; my $key = '1'; my $ssh_start_vip = "/sbin/ifconfig eth1:$key $vip"; my $ssh_stop_vip = "/sbin/ifconfig eth1:$key down"; ... ... |
4.启动前手动绑定VIP
|
1 2 3 4 5 6 7 8 9 10 11 |
#绑定子网卡 [root@db02 ~]# ifconfig eth1:1 172.16.1.55/24 3: eth1: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP group default qlen 1000 link/ether 00:0c:29:41:0e:db brd ff:ff:ff:ff:ff:ff inet 172.16.1.52/24 brd 172.16.1.255 scope global eth1 valid_lft forever preferred_lft forever inet 172.16.1.55/24 brd 172.16.1.255 scope global secondary eth1:1 valid_lft forever preferred_lft forever #解绑网卡 [root@db02 ~]# ifconfig eth1:1 down |
5.启动MHA
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 |
#停止mha [root@db03 ~]# masterha_stop --conf=/service/mha/app1.cnf Stopped app1 successfully. #启动mha [root@db03 ~]# nohup masterha_manager --conf=/service/mha/app1.cnf --remove_dead_master_conf --ignore_last_failover < /dev/null > /service/mha/app1/manager.log 2>&1 & #启动失败 1.检查是否有执行权限 [root@db03 ~]# chmod +x /service/mha/master_ip_failover 2.语法是否正确 3.文件格式 [root@db03 ~]# yum install -y dos2unix [root@db03 ~]# dos2unix /service/mha/master_ip_failover dos2unix: converting file /service/mha/master_ip_failover to Unix format ... |
6.测试VIP漂移
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 |
#从库查看主库信息 [root@db03 ~]# mysql mysql> show slave status\G *************************** 1. row *************************** Slave_IO_State: Waiting for master to send event Master_Host: 172.16.1.52 Master_User: rep Master_Port: 3306 #主库查看IP [root@db02 ~]# ip addr 3: eth1: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP group default qlen 1000 link/ether 00:0c:29:41:0e:db brd ff:ff:ff:ff:ff:ff inet 172.16.1.52/24 brd 172.16.1.255 scope global eth1 valid_lft forever preferred_lft forever inet 172.16.1.55/24 brd 172.16.1.255 scope global secondary eth1:1 valid_lft forever preferred_lft forever #停止主库 [root@db02 ~]# systemctl stop mysqld #再次查看主库信息 [root@db03 ~]# mysql mysql> show slave status\G *************************** 1. row *************************** Slave_IO_State: Waiting for master to send event Master_Host: 172.16.1.51 Master_User: rep Master_Port: 3306 Connect_Retry: 60 #查看新主库的IP [root@db01 ~]# ip addr 3: eth1: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP group default qlen 1000 link/ether 00:0c:29:6c:a6:c6 brd ff:ff:ff:ff:ff:ff inet 172.16.1.51/24 brd 172.16.1.255 scope global eth1 valid_lft forever preferred_lft forever inet 172.16.1.55/24 brd 172.16.1.255 scope global secondary eth1:1 valid_lft forever preferred_lft forever |
